Technical Parameter:
Type | RS6×2000 | RS8×2000 | RS10×2200 | RS2×2200 | RS16×2200 |
Thickness Range (mm) | 1-6 | 2-8 | 2-10 | 3-12 | 4-16 |
Width Range (mm) | 2000 | 2000 | 2200 | 2200 | 2200 |
Cutting Length (mm) | 500-6000 | 600-8000 | 600-10000 | 800-12000 | 800-12000 |
Cutting Precision (mm) | ±0.5 | ±1 | ±1 | ±1 | ±1 |
Roller Numbers | 15 | 13 | 13 | 11 | 11 |
Roller Diameter | Ф140 | Ф155 | Ф160 | Ф180 | Ф200 |
Coil ID Linear Speed |
Ф508&610mm 0~28m/min or 0-60m/min |
Ф&610&760mm 0~28m/min or 0-60m/min |
Ф610&760mm 0~28m/min
| Ф610&760mm 0~28m/min | Ф610&760mm 0~28m/min |
Model | RS-1.2 | RS-2.0 | RS-3.0 | RS-4.0 |
Coil Material | δs≤230N/mm2,Cold-rolled Coil, Stainless Steel Coil, Galvanized Coil ,AL ,Copper | |||
Coil Thickness | 0.11~1.2mm | 0.2~2.0mm | 0.3~3.0mm 0.5-4.0mm | |
Coil Width | 300~800mm | 800~1250mm | 800~1250/1600mm 800~1600/1800mm | |
Coil Weight | ≤10T | ≤20T | ≤20T(25T) ≤25T(30T) | |
Coil I.D | ф508mm | ф508mm | ф508&ф610mm ф508& ф610mm | |
Coil O.D | ≤ф1800mm | ≤ф1800mm | ≤ф2000mm ≤ф2000mm | |
Cutting Range | 300~3000mm | 300~4000mm | 300~4000mm 300~4000mm | |
Cutting Accuracy | ±0.3mm | ±0.3mm | ±0.5mm ±0.5mm | |
Roller Diameter | ф65(50) | ф65(50) | Ф 85(65) Ф 100(80) | |
Linear Speed | 0~60m/min | 0~60m/min | 0~60m/min 0~60m/min | |
Control System | PLC Automatic control | PLC Automatic control | PLC Automatic control PLC Automatic control |
